24VDC - 2-Sync Hall Effect Control Box with Presets

Name: 24VDC - 2-Sync Hall Effect Control Box with Presets
Brand: Progressive Automations
SKU: FLTCON-2-24VDC
Price: 146.99 USD
Availability: InStock

Description

FLTCON-2-24VDC Specifications

The FLTCON-2-24VDC is a 2-channel Hall effect control box that synchronizes travel between two identical linear actuators, lifting columns or table lifts. This control box is similar to our FLTCON-2, however is designed for 24 VDC applications and an output current maximum of 15A. You can pair the FLTCON-2-24VDC with many of our products including our PA-04-HS Hall effect actuators or with a 24VDC power source to power up our FLT-02 table lift, giving you full mobility!

The FLTCON-2-24VDC does not include a wired remote, however, you can check out our Hand Remote section to choose the most suitable remote for your application. Pro-tip: you can program and set up to 4 memory positions by using the RT-11 handset remote for ultimate convenience!

For wireless Bluetooth app control, you can also pair the FLTCON-2-24VDC with the RT-BT1 Bluetooth dongle to control compatible systems directly from your smartphone using the Progressive Motion app.

The Progressive Motion app is available for download from the App Store and Google Play.

Please contact sales@progressiveautomations.com for programming requirements for this product.

FLTCON-2-24VDC Compatibility Chart

Overview

FLTCON-2-24VDC Specifications

The FLTCON-2-24VDC is a 2-channel Hall effect control box that synchronizes travel between two identical linear actuators, lifting columns or table lifts. This control box is similar to our FLTCON-2, however is designed for 24 VDC applications and an output current maximum of 15A. You can pair the FLTCON-2-24VDC with many of our products including our PA-04-HS Hall effect actuators or with a 24VDC power source to power up our FLT-02 table lift, giving you full mobility!

The FLTCON-2-24VDC does not include a wired remote, however, you can check out our Hand Remote section to choose the most suitable remote for your application. Pro-tip: you can program and set up to 4 memory positions by using the RT-11 handset remote for ultimate convenience!

For wireless Bluetooth app control, you can also pair the FLTCON-2-24VDC with the RT-BT1 Bluetooth dongle to control compatible systems directly from your smartphone using the Progressive Motion app.

The Progressive Motion app is available for download from the App Store and Google Play.

Please contact sales@progressiveautomations.com for programming requirements for this product.

FLTCON-2-24VDC Compatibility Chart

Product Specifications

Input Voltage:

24VDC

Unit Weight:

0.56 lbs

Warranty:

18 Months

Control Boxes Compatibility

Model	Subcategory	Control Boxes Compatibility	Integration Requirements
Model FLTCON-2-24VDC	Subcategory Output 24VDC	Control Boxes Compatibility Stock Actuator: PA-04-HS-24VDC, PA-TS1, PA-09-HS, PA-10-HS, PA-01-HS Table lifts: FLT-02	Integration Requirements Prior to shipping our FLTCON series of control boxes, they require programming for the specific model of the product(s) you plan to use. For more information, feel free to contact our team of engineers and we'll be happy to assist you.

Technical Information

Following a set of standards is crucial for businesses to ensure their products and services can meet a level of quality that promotes customer satisfaction. At Progressive Automations, we aim for nothing but the best for our customers and strive toward continual improvements. Because of this, we are excited to announce that Progressive Automations is now ISO 9001:2015 certified!

Quality Assured

Data Sheets

FLTCON-2-24VDC Manual

User Manual for FLTCON-2-24VDC

View

PDF

Knowledge base

Video & Articles

Videos

FLTCON Control Box to Home Automation Compatibility

November 12, 2024Nathan Bong

Home automation significantly enhances the convenience, safety, and overall efficiency of numerou...

Learn more

FAQ

What are the key differences between the FLTCON-2-24VDC and the FLTCON-2, and when should I choose one over the other?

Their power input differences; where FLTCON-2 accepts 110 VAC input voltage, while FLTCON-2-24VDC accepts 24 VDC input voltage. Choose a control box based on the source of power that is available around your installation.

What types of actuators and lifting columns are compatible with the FLTCON-2-24VDC control box?

Ensure FLTCON-2-24VDC compatibility by selecting actuators and lifting columns that have hall effect sensor feedback, 24 VDC operation, and current draw no higher than 15A combined. To ensure plug-and-play synchronization, the setup requires two identical columns or two identical actuators paired together, similar wire length, and a reset procedure for initial setup. For more information, check our Control Boxes Compatibility Chart.

How do I configure memory presets with the RT-11 remote and how many positions can be saved?

With an RT-11 handset remote, move to a desired position using the UP and DOWN buttons, and then press a preset key to save; tap this preset key to recall the desired position. The FLTCON control boxes can store up to four actuator memory presets.

What are the current and voltage limits of the FLTCON-2-24VDC and what power supply should be used?

The FLTCON-2-24VDC accepts 24VDC input power and outputs 24VDC with a maximum total current output of 15A. Select a 24V power supply that can also meet the actuator input requirements for the total current draw of both actuators.

Does the FLTCON-2-24VDC include a wired remote, and which remote is recommended for full preset functionality?

We offer a wide range of compatible hand remotes (wired and wireless) that offer various unique features, sold separately. The RT-11 is the most popular of our FLTCON-2-24VDC remote options that offer four memory presets, basic up/down keypads, and an LED display.
