Waterproof Linear Actuator IP68M

Waterproof Linear Actuator IP68M

Model: PA-10

Out of stock
Back in stock soon
Volume Discount
1-6 units 187.00
7-9 units 177.65
10–19 units 168.30
20–49 units 149.60
Regular price $187.00 USD
Regular price Sale price $187.00 USD
Sale Sold out
Voltage - 12 VDC
Feature - Standard
Stroke - 2 inch
  • Linear Actuator Calculator
  • Get Free Actuator Guide
  • Created with Fabric.js 1.7.22 You may also need these
View full details

Description
PA-10 Specifications

The PA-10 waterproof electric linear actuator has a weather protection rating of IP68 M and IP69K, allowing the actuator to be fully submerged while in motion and can withstand high-powered water jets while not in motion. It features the highest IP rating amongst the Progressive Automations’ line of products. In combination with the PA-10’s compact size and high-force rating, it makes it excellent for marine, automotive, and agricultural applications.



For applications that require added corrosion resistance, the PA-10 is available in a Salt Spray rated version which features specialized porcelain plated housing. This has been vigorously tested for up to 400 hours of salt spray exposure, ensuring that it will perform in the harshest environments.

For more information on specifications, dimensional drawings, and customization options, please see the PA-10 datasheet. Please see the IP-Rating Guide for more information on these ratings.

Actuators Comparison Chart

MOUNTING OPTIONS:

The BRK-09 bracket, compatible with the PA-10, can be used on either the stroke or motor-end mounting locations and allows for over 180° rotation.

CONTROL SYSTEMS:

The PA-10 features a highly efficient drive system that requires very low power. At maximum load, it will draw less than 6.0A at 12VDC. This is a great power-saving feature for applications using batteries. It also makes the PA-10 easier to integrate into existing control systems, as well as the various control systems we have available.

BROWSE MORE ACTUATORS

Custom options

Looking for an actuator but the specifications don't exactly match what you require? We have an extensive list of customization capabilities to ensure you get exactly what you need for your project. Download this product's data sheet and find out more about your customization options!

Overview
PA-10 Specifications

The PA-10 waterproof electric linear actuator has a weather protection rating of IP68 M and IP69K, allowing the actuator to be fully submerged while in motion and can withstand high-powered water jets while not in motion. It features the highest IP rating amongst the Progressive Automations’ line of products. In combination with the PA-10’s compact size and high-force rating, it makes it excellent for marine, automotive, and agricultural applications.



For applications that require added corrosion resistance, the PA-10 is available in a Salt Spray rated version which features specialized porcelain plated housing. This has been vigorously tested for up to 400 hours of salt spray exposure, ensuring that it will perform in the harshest environments.

For more information on specifications, dimensional drawings, and customization options, please see the PA-10 datasheet. Please see the IP-Rating Guide for more information on these ratings.

Actuators Comparison Chart

MOUNTING OPTIONS:

The BRK-09 bracket, compatible with the PA-10, can be used on either the stroke or motor-end mounting locations and allows for over 180° rotation.

CONTROL SYSTEMS:

The PA-10 features a highly efficient drive system that requires very low power. At maximum load, it will draw less than 6.0A at 12VDC. This is a great power-saving feature for applications using batteries. It also makes the PA-10 easier to integrate into existing control systems, as well as the various control systems we have available.

BROWSE MORE ACTUATORS

Custom options

Looking for an actuator but the specifications don't exactly match what you require? We have an extensive list of customization capabilities to ensure you get exactly what you need for your project. Download this product's data sheet and find out more about your customization options!

Force, Speed & Current
Product Specifications
Length & Weight
Brackets Compatibility
Control Boxes Compatibility
Technical Information

Following a set of standards is crucial for businesses to ensure their products and services can meet a level of quality that promotes customer satisfaction. At Progressive Automations, we aim for nothing but the best for our customers and strive toward continual improvements. Because of this, we are excited to announce that Progressive Automations is now ISO 9001:2015 certified!

Read More

Data Sheets

PA-10 User Manual

User Manual for PA-10

View

2D/3D models

Video & Articles
Videos
Related blog articles:
How to Prevent Water Damage to your Actuator

How to Prevent Water Damage to your Actuator

Nathan Bong

Electric Linear Actuators are used to automate different types of applications in different envir...

Learn more
ATX West 2020 Trade Show

ATX West 2020 Trade Show

David Eidelshtein

Progressive Automations just got back from the ATX West show. This trade show and conference are ...

Learn more
Photo of PA-10  actuator with salt spray rating protection

Salt Spray Testing to Evaluate Corrosion Resistance

Mark Luciano

A salt spray test is a standardized and popular testing method conducted to evaluate corrosion re...

Learn more
Support
FAQ
How Can I Determine Which Progressive Automations Linear Actuator is Best Suited for My Application?

Depending on your application, there are different specification requirements you should consider when determining the linear actuator you need. These requirements include force, stroke, speed and mounting dimensions. For detailed actuator information, you can refer to either the datasheet or the specification table located on the selected actuator's product page. You can also contact us to speak with one of our expert engineers.

What Is Duty Cycle and How Is It Calculated?

Duty cycle is the fraction of the working period in which a linear actuator can remain active. You can calculate the duty cycle of a linear actuator by using the following equation: Duty cycle (%) = (Time the linear actuator is active) / (Time for one working period)

For example: With a 25% duty cycle, an actuator can run for 5 minutes continuously before needing to rest for 15 minutes before operating.

What Does Stroke Mean? How Am I Supposed to Know Which Size to Choose?

Stroke is the travel distance of the extending rod. To find the stroke length you require, measure your application from the fully retracted position to the fully extended position. The difference will equal the stroke length you require.

How Do I Know Which Force Rating Is Right for My Application?

We always recommend purchasing an actuator with a higher force rating than what the application requires. If unsure of your force requirements, this article may help you calculate this: How to Calculate Force to Find the Right Linear Actuator

Can I Synchronize My Linear Actuators?

Yes, this is possible. However, it does depend on the units you are currently using. To synchronize actuators, they require a form of feedback such as a potentiometer or hall effect sensors. For more information, see below some of our key content regarding linear actuator synchronization.

Controlling Multiple Linear Actuators at the Same Time

How To Utilize FLTCON-2 & FLTCON-4 Control Boxes?

What Are the Control Box Options For My Actuator?

The control box you choose should be able to provide sufficient voltage and current rating to your actuator. If you are unsure of the specifications, please contact us.

Alternatively, you can also find compatible control boxes on your selected linear actuator's product page.

What Is Backdriving? -- What Does Dynamic and Static Load Ratings Mean? -- What Is Lateral Loading?
What Is Backdriving?

Backdriving is when an actuator starts sliding down under load, when it is either overloaded or when the actuator has been damaged. Watch the video.

What Does Dynamic and Static Load Ratings Mean?

Dynamic load rating is the amount of weight an actuator can pull or push safely when being powered. Static load rating is the amount of weight the actuator can hold or withstand without back driving when it is not being powered. For example, let's just say you have an actuator installed on a window and the static load rating of the actuator is 100lbs, it could experience backdriving when there is a high wind event, which means there will be more pressure exerted on the actuator which would exceed the 100lbs load rating of the actuator.

What Is Lateral Loading?

Lateral loading is when the actuator experiences forces from the lateral plane. Actuators are not meant to handle lateral forces at all so if it experiences any lateral forces, it will likely damage the actuator or bend the rod. So it's advised never to use lateral forces and always make sure the actuator is fully in line or in sync with your application, so it does not take any load other than the axial load. Watch the video.

Customer Reviews

Based on 3 reviews
100%
(3)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
B
Ben
Actuator works, support is non-existent

Don't bother trying to get support. The person I got online with for help with an electrical issue could not understand that the steel bracket had no electrical components and that it was not in any way related to my question. Requests for more competent assistance resulted in no assistance at all, and being cut off. Manual is not complete. Youd better not have any questions about your application because they will not be answered here.

Hi Ben,

Thank you for taking the time to leave feedback regarding your experience with our product and support services. We apologize for any frustration or inconvenience you encountered.

After thoroughly investigating your case, it appears that we did not receive any communication from you regarding the electrical issue you faced. We strive to provide comprehensive support to all our customers, and it's disappointing to learn that you didn't receive the assistance you needed.

We genuinely regret any inconvenience this situation may have caused you and would like to make things right. Please reach out to us directly with any further concerns or questions you may have, and we'll do our best to assist you promptly. You can give us a call at 1-800-676-6123 or send us an email at sales@progressiveautomations.com.

Thank you for bringing this matter to our attention, and we hope to have the opportunity to restore your trust in our products and services.

D
David Gardner
Very impressed!

Very impressed! I used two actuators to automate windows in our greenhouse via thermostat or manually by toggle switch. Their actuators and relay/base, all that was needed is imagination. Maybe a little $. Very satisfied, compact, strong and attractive actuators.

Hello David,

Thank you so much for such a positive review of our products. We're so glad that the Waterproof Linear Actuator has met your expectations for your window automation.

Please feel free to contact us if you have any further questions or concerns in the future. Our team of technical product engineers or customer service representatives would be more than happy to assist you.

Happy New Year!
Loureal - Progressive Automations Team

F
Fred
Waterproof Linear Actuator IP68M 12 VDC / Salt Spray Rating / 16 inch

I was quoted an exorbitant amount for a replacement actuator for an Arcadia brand louvered pergola system. I found Progressive Automations by luck searching the web for linear actuators. After asking a few questions I settled on this PA-10 model. I couldn't be happier. I had to climb up on the roof myself, but for the money I could spend an hour installing the motor, testing it, and enjoying a cold refreshment to celebrate a job well done. The motor is faster and quieter than the old one. I'm looking into having them do a custom actuator, just because this one worked so well. The other option will be buying an external limit switch (AC-24) which I may do as well. Super customer service, a solid product and a reasonable price. How could this be anything other than a 5 start review!

We greatly appreciate your feedback, Fred! Thank you for choosing Progressive Automations. Your satisfaction is our priority, and we're here to help with any future needs or questions you may have.
